Technology Technology

Cómo comprobar capacitores dañados y medir su ESR por @1gPolo

Vote
751 751 views
3y Feb 15, 2020
G

En este video te muestro cómo medir la #ESR (Resitencia Serie Equivalente) en los #capacitores o condensadores, para poder determinar si están dañados. En muchos casos una elevada ESR se manifiesta con capacitores inflados, pero no siempre es así. La medición de este parámetro se puede hacer con el Capacheck, el Blue ESR Tester, o uno de los probadores hechos con base en el ATMEGA328.

¿Te insteresa adquirir un pobador de ESR? Considera las siguientes opciones (enlaces de afiliado):
Blue ESR Tester: https://amzn.to/2CrT7ou
Atlas ESR70: https://amzn.to/32yLMhx
Genérico: https://amzn.to/2CPnMMp
Algunos me preguntan cuál es el desoldador que utilizo casi al final, es este:
Hakko FR301: https://amzn.to/3fIMNXX

00:00 ¿Qué es la ESR?
00:34 Fallo en equipos por la ESR
01:12 Opciones para medir la ESR
01:43 CapaCheck de Creatrónica
03:25 BlueESR Tester de AnaTek Instruments
04:21 Medidor de ESR genérico
05:25 Probador multicomponentes (ATMEGA328)
06:06 Comprobación de algunos capacitores con el BlueESR
08:15 Comprobación de capacitores en placa
10:05 Despedida

- - -
Página web: https://www.1gpolo.com
Twitter: https://www.twitter.com/1gPolo

About ingePolo

Hello, my name is Polo. I am an electronic engineer and I will be sharing videos of repairs, testing of components, reviews of tools and instruments, tutorials, projects, home tools, tips, among other things. (Spanish spoken)
